RXR26 High Voltage Contactor 250A 1500VDC
RXR26 High Voltage Contactor 250A 1500VDC
The Rincon Power RXR26 is a ceramic-sealed high voltage DC contactor for 250 A in 1500 VDC energy storage, charging and industrial systems.
250 A continuous, 1000 A overload for 30 s
Rated for 1500 VDC, breaks 2000 A at 1000 V
Bi-directional SPST-NO main contacts
Hermetic ceramic seal, exceeds IP69
12 or 24 VDC coil, bottom or side mount
Optional normally open auxiliary contact
-40 to +100 °C, 500,000 mechanical cycles
Our guides help you choose the right product.
Relay vs contactor vs SSR – which should you choose?Additional information
| Sector | Renewables, Vehicle Solutions |
|---|---|
| Auxiliary contact | Normally open (NO) |
| Coil Voltage | 12 VDC, 24 VDC |
| Contact config | Normally open (NO), SPST |
| Continuous current | 250 A DC |
| Max current | 250 A DC |
| IP Classification | Hermetic, IP69 |
| Mechanical cycles | 500.000 |
| Temperature range | -40°C ~ 100°C |
| Max system voltage | 1500 VDC |
| Current direction | Bidirectional |
| Shock | 20 G |
| Weight | 440 g |
| Response time | 30 ms |
| Power consumption | 7 W |
