GV240 Contactor / 100-800 V dc
GV240 Contactor / 100-800 V dc
GV240 is a hermetically sealed power contactor for DC systems from 100 to 800 VDC and 400 A, suited to battery-powered vehicles.
400 A continuous current, 100–800 VDC system voltage
Hermetic, IP67 and IP69K, -55 °C to +85 °C
Ignition protection to SAE J1171 and ISO8846
Low-power dual coil 12, 24 or 48 VDC
PWM coil options and built-in coil suppression
Side, upright or PCB mounting, NO auxiliary contact
Class I Div 2 (UL1604) and MIL-STD-810
Our guides help you choose the right product.
Relay vs contactor vs SSR – which should you choose?Additional information
| Auxiliary contact | Normally open (NO) |
|---|---|
| Coil Voltage | 12 VDC, 24 VDC, 48 VDC |
| Contact config | Normally open (NO) |
| Continuous current | 400 A DC |
| Mechanical cycles | 1.000.000 |
| Mounting | PCB, Side, Up-Right |
| Sector | Vehicle Solutions |
| IP Classification | Hermetic, IP67, IP69K |
| Temperature range | -55°C ~ 85°C |
| Max system voltage | 800 VDC |
| Current direction | Unidirectional |
| Approvals | Class I Div 2, MIL-STD-810 |
| Weight | 0,38 kg, 0,45 kg |
| Shock | 50 G |
| Vibration | 25 G |
| Response time | 25 ms |
