GV120 Contactor / 12-100 V dc
GV120 Contactor / 12-100 V dc
Hermetically Sealed – Designed to meet: UL1604 for Class I & II, Div 2 and Class III for use in hazardous locations, IP67 for temporary water immersion for 30 min, SAE J1171 – external ignition protection, and ISO8846 for protection against ignition around flammable gasses.
Built-in coil suppression for all DC coils – Saves you engineering time and parts cost to add external coil suppression.
Our guides help you choose the right product.
Relay vs contactor vs SSR – which should you choose?Additional information
| Auxiliary contact | Normally open (NO) |
|---|---|
| Coil Voltage | 12 VDC, 24 VDC, 48 VDC |
| Contact config | Normally open (NO) |
| Continuous current | 225 A DC |
| Mechanical cycles | 1.000.000 |
| Mounting | PCB, Side, Up-Right |
| Sector | Vehicle Solutions |
| IP Classification | Hermetic, IP67, IP69K |
| Temperature range | -55°C ~ 85°C |
| Max system voltage | 100 VDC |
| Approvals | Class I Div 2, MIL-STD-810 |
| Weight | 0,38 kg, 0,45 kg |
| Shock | 35 G |
| Vibration | 25 G |
| Response time | 30 ms |
