REC35 Hermetically Sealed Contactors 500A 1000VDC
REC35 Hermetically Sealed Contactors 500A 1000VDC
Hermetic seal with gas fill
Optional auxiliary contacts – for main position feedback
Integrated coil economizer to reduce coil holding power
Meets RoHS 2011/65/EU
CE certified
IEC60947-4-1 compliant
CHARACTERISTIC
Contact Arrangement Form X, SPST NO
Max Switching Voltage 1000VDC
Continuous Current (2 x 127mm2 conductor) 500A
Overload Current 1 minute 1,000A
5 Minutes 650A
Operating Temperature -40˚C to 85˚C
Ingress Protection Exceeds IP69, (Hermetically sealed)
Mechanical life 500,000
Our guides help you choose the right product.
Relay vs contactor vs SSR – which should you choose?Additional information
| Auxiliary contact | Normally closed (NC), Normally open (NO), Optional |
|---|---|
| Coil Voltage | 32–95 VDC, 9–36 VDC |
| Contact config | Normally open (NO), SPST |
| Continuous current | 500 A DC |
| IP Classification | Hermetic, IP69 |
| Max current | 250 A DC |
| Mechanical cycles | 500.000 |
| Mounting | PCB |
| Sector | Vehicle Solutions |
| Max system voltage | 1000 VDC |
| Temperature range | -40°C ~ 85°C |
| Current direction | Bidirectional, Unidirectional |
| Approvals | UL |
| Shock | 20 G |
| Response time | 25 ms |
| Weight | 430 g |
