GV220 Contactor / 100-800 V dc
GV220 Contactor / 100-800 V dc
GV220 is a hermetically sealed, cost-effective DC contactor for vehicle power systems up to 800 VDC, available for PCB, side or upright mounting.
225 A continuous at up to 800 VDC
Hermetic, IP67 and IP69K, -55 °C to +85 °C
12, 24 or 48 VDC coil with built-in suppression
NO auxiliary contact, not position sensitive
Stainless steel hardware and brass mounting inserts
380 g or 450 g, shock 35 G, vibration 25 G
Class I Div 2, MIL-STD-810, UL1604, SAE J1171, ISO8846
Our guides help you choose the right product.
Relay vs contactor vs SSR – which should you choose?Additional information
| Auxiliary contact | Normally open (NO) |
|---|---|
| Coil Voltage | 12 VDC, 24 VDC, 48 VDC |
| Contact config | Normally open (NO) |
| Continuous current | 225 A DC |
| Mechanical cycles | 1.000.000 |
| Mounting | PCB, Side, Up-Right |
| Sector | Vehicle Solutions |
| IP Classification | Hermetic, IP67, IP69K |
| Temperature range | -55°C ~ 85°C |
| Max system voltage | 800 VDC |
| Current direction | Unidirectional |
| Approvals | Class I Div 2, MIL-STD-810 |
| Weight | 0,38 kg, 0,45 kg |
| Shock | 35 G |
| Vibration | 25 G |
| Response time | 30 ms |
