DP350 TouchMATRIX with its start-stop interface
DP350 TouchMATRIX with its start-stop interface
DP350 is a touchMATRIX panel indicator with start-stop interface for position measurement with magnetostrictive and absolute position encoders.
Resistive touchscreen with event-based red, green or yellow display
Init pulse frequency adjustable from 62.5 Hz to 5 kHz
Scaling, filter, zero offset and 24-point linearisation
5 V or 24 V supply output for the encoder
Options for 16-bit analog output, relays and RS232/RS485
96 x 48 mm housing with IP65 front, 18–30 VDC
Additional information
| Sector | Factory Automation |
|---|---|
| Temperature range | -20°C ~ 60°C |
| Supply voltage | 115–230 VAC, 18–30 VDC |
| IP Classification | IP65 front |
| Mounting | Panel |
| Material | Plastic |
| Dimensions | 96 x 48 x 116 mm |
| Weight | 200 g |
| Touch | Resistive |
| Digital inputs | 3 |
| Digital outputs | 4 |
| Analog outputs | 1 |
| Fieldbus/Interface | RS-232, RS-485 |
| Serial standard | RS-232, RS-485 |
| Contact config | Change over (CO) |
