iP series HMI panels, 4.3 to 10.1 inch
iP series HMI panels, 4.3 to 10.1 inch
The Weintek iP series is a slim HMI family with resistive touch for panel mounting, in three sizes for machines and smaller control systems.
MT8052iP: 4.3-inch, 480 × 272, 400 cd/m²
MT8072iP: 7-inch, 800 × 480, 450 cd/m²
MT8106iP: 10.1-inch WVA, 1024 × 600, 350 cd/m²
4-wire resistive touch, 256 MB flash and 128 MB RAM
Ethernet, USB host and 2–3 COM ports (RS-232/RS-485)
24 VDC with built-in power isolation
NEMA4/IP65 front, 0 to 55 °C, CE marked
Additional information
| Sector | Factory Automation |
|---|---|
| IP Classification | IP65 front |
| Screen size | 10,1'', 4.3'', 7'' |
| Touch | Resistive |
| Mounting | Panel |
| Temperature range | 0°C ~ 55°C |
| Material | Plastic |
| Supply voltage | 24 VDC |
| Dimensions | 128 x 102 x 32 mm, 200,4 x 146,5 x 34 mm, 271 x 213 x 36,4 mm |
| Weight | 0,25 kg, 0,52 kg, 1 kg |
| Display resolution | 1024×600, 480×272, 800×480 |
| Brightness (nits) | 350 nits, 400 nits, 450 nits |
| LAN ports | 1 |
| USB ports | 1 |
| COM ports | 2, 3 |
| Serial standard | RS-232, RS-485 |
| Vibration | 2 G |
| Memory | 128MB |
| Fieldbus/Interface | Ethernet, RS-232, RS-485, USB |
