TP304-SM
TP304-SM
Yaskawa TP304-SM is a 4.3-inch HMI touch panel with 1 GHz processor and IP66 front for machine operation and visualization.
4.3-inch resistive touch display, 480 x 272
ARM Cortex-A8 processor at 1 GHz
512 MB work memory, 4 GB user memory
IP66 front for panel mounting
RS232/422/485, USB-A and RJ45 Ethernet
Windows Embedded Compact 7 with Movicon CE Standard
24 VDC, 6 W, 0 to 50 °C, UL approved
Our guides help you choose the right product.
HMI and operator panels – how to chooseAdditional information
| IP Classification | IP66 front |
|---|---|
| Programming software | Movicon |
| Screen size | 4.3'' |
| Mounting | Panel |
| Sector | Factory Automation |
| Material | Plastic |
| Processor | ARM Cortex-A8 |
| Operating system | Windows |
| Touch | Resistive |
| Display resolution | 480×272 |
| Supply voltage | 24 VDC |
| Power consumption | 6 W |
| Temperature range | 0°C ~ 50°C |
| Weight | 291 g |
| Approvals | UL |
| Fieldbus/Interface | Ethernet, RS-232, RS-485, USB |
| Serial standard | RS-232, RS-422, RS-485 |
| COM ports | 1 |
| LAN ports | 1 |
| USB ports | 1 |
| Memory | 512MB |
