TP304-SM operaatoripaneel
TP304-SM operaatoripaneel
Yaskawa TP304-SM on 4,3-tolline HMI-puutepaneel 1 GHz protsessori ja IP66 esiosaga masinate juhtimiseks ja visualiseerimiseks.
4,3-tolline resistiivne puuteekraan, 480 x 272
ARM Cortex-A8 protsessor, 1 GHz
512 MB töömälu, 4 GB kasutajamälu
IP66 esiosa paneelpaigalduseks
RS232/422/485, USB-A ja RJ45 Ethernet
Windows Embedded Compact 7 ja Movicon CE Standard
24 VDC, 6 W, 0 kuni 50 °C, UL-heakskiiduga
Meie juhendid aitavad teha õige valiku.
HMI ja operaatoripaneelid – kuidas validaLisainfo
| IP-klass | IP66 esikülg |
|---|---|
| Programmeerimistarkvara | Movicon |
| Ekraani suurus | 4,3'' |
| Paigaldus | Paneel |
| Sektor | Tehaseautomaatika |
| Materjal | Plast |
| Protsessor | ARM Cortex-A8 |
| Operatsioonisüsteem | Windows |
| Puuteekraan | Resistiivne |
| Ekraani eraldusvõime | 480×272 |
| Toitepinge | 24 VDC |
| Energiatarve | 6 W |
| Temperatuurivahemik | 0°C ~ 50°C |
| Kaal | 291 g |
| Sertifikaadid | UL |
| Väljasiin/liides | Ethernet, RS-232, RS-485, USB |
| Jadaliidese standard | RS-232, RS-422, RS-485 |
| COM-pordid | 1 |
| LAN-pordid | 1 |
| USB-pordid | 1 |
| Mälu | 512MB |
