SOB564330 Solid State Relay 40A
SOB564330 Solid State Relay 40A
The Celduc SOB564330 is a dual-channel solid state relay for AC-51 resistive loads, built for compact heater control in industrial panels.
2 × 40 A rating, 25 A continuous via quick-connect terminals
24–600 VAC zero-cross output with 1200 V peak voltage
TMS2 thyristors for long service life
IP20 6.3 mm quick-connect power terminals, heatsink mounting
Dual 10–30 VDC input via 4-pin locking flat-cable plug
Designed to EN 60947-4-3, cURus
Our guides help you choose the right product.
Relay vs contactor vs SSR – which should you choose?Additional information
| Control voltage | 10–30 VDC |
|---|---|
| Max current | 25 A AC |
| Max system voltage | 24–600 VAC |
| Phase | 2-phase |
| Sector | Factory Automation |
| IP Classification | IP20 |
| Temperature range | -55°C ~ 100°C |
| Approvals | UL |
| Weight | 80 g |
| Response time | 10 ms |
| Vibration | 10 G |
| Shock | 30 G |
| Material | Aluminium, Plastic |
| Electrical connection | Quick-connect 6,3 mm |
