P800 150 A solid state power controller
P800 150 A solid state power controller
The Leach P800 is a 28 Vdc, 150 A solid state power controller that combines switching, overload protection and status reporting for aircraft power distribution.
150 A load current at 28 Vdc, 75 A and 220 A variants
Power FET output, under 300 mV voltage drop
Built-in overload and short circuit protection
Opto-isolated load and trip status outputs, 500 Vrms
Isolated control power input, 16 to 33.5 Vdc
Full rated current up to +90 °C case temperature
80 x 96 x 45 mm, 500 g, MTBF 62,000 h, DO-160
Additional information
| Sector | Defence |
|---|---|
| Rated voltage | 28 VDC |
| Max current | 150 A DC |
| Supply voltage | 16–33,5 VDC |
| Temperature range | -40°C ~ 90°C |
| Dimensions | 80 x 96 x 45 mm |
| Weight | 500 g |
| MTBF | 62.000 h |
| Approvals | DO-160 |
