P20M pressure switch, settings from 1 to 30 psig
P20M pressure switch, settings from 1 to 30 psig
The Precision Sensors P20M is a gauge pressure switch for liquid or gaseous media, such as fuel, hydraulic oil and engine bleed air.
Settings from 1 to 30 psig, repeatability 0.1 psig + 2%
Proof pressure 200 psig, operating from -65 to 250 °F
Polyimide diaphragm and Belleville spring for long cycle life
Hermetically sealed switch where vapor ignition is a concern
SPST to DPDT contacts, 7 Amps max. at 28 VDC
MS or pipe fittings, mil-spec connector or free leads
High temperature and custom versions available
Our guides help you choose the right product.
IP ratings explained – IP65, IP67, IP68 and IP69KPressure transducer vs transmitter vs switch – how to chooseAdditional information
| Pressure limit PSI | 1 |
|---|---|
| Sector | Defence |
| Measured variable | Pressure |
| Measuring range | 1-30psig |
| Temperature range | -54°C ~ 121°C |
| Max current | 5 A DC |
| Voltage | 250 VAC, 28 VDC |
| Material | Aluminium, Stainless steel |
| Electrical connection | Free leads, MIL connector |
| Process connection | MS fitting, Pipe fitting |
| Weight | 136 g |
