Box-PC

Box-PCs are compact industrial computers in an enclosed chassis, designed for installation in control cabinets, machines and vehicles. SCN supplies Box-PCs from Aitech, Aaeon and Axiomtek, including fanless embedded systems, DIN rail mount computers, compact edge AI systems, medical grade PCs and I/O expansion and mass storage units for rugged systems. They are used in industrial automation, machine building, vehicles, defence and aerospace, and medical technology. Our engineers help you choose the right processor platform, interfaces, mounting and cooling for your application.

Solution areas

Product categories

Filter by attributes

Acceleration

Accuracy (°)

Accuracy (%)

Approvals

Auxiliary contact

Built-in I/O

Capacity

Circuits

Coil Voltage

Communication Interface

Switching output

Contact config

Mechanical cycles

Continuous current

Control voltage DC

Control voltage AC

CPU performance

Data logging

DIN-rail

Electrical connection

Number of poles

Coding

Connector design

Cable jacket

Expansion slots

Fieldbus/Interface

Flange size

Function

Housing

I/O slave module

IP Classification

Load Cell Type

Material

Material in contact with medium

Max current DC

Max current AC

Max operating speed

Max system voltage DC

Max system voltage AC

Measuring range (mm)

Measuring range (bar)

Measuring range (kg)

Measuring range (°C)

Measuring range (°)

Torque

Power (kW)

Digital inputs

Digital outputs

Analog inputs

Analog outputs

Measuring range (l/min)

Measuring range (kHz)

Measuring technology

Measured variable

Memory

Modules

Mounting

Nominal diameter

Number of ports

Operating system

Outer Diameter

Output Voltage

Output current

Efficiency

Phase

Photocell type

Positions

Pressure type

Pressure limit PSI

Process connection

Probe length

RAID

Rated power

Remote Access

Resolution Multiturn

Resolution Singleturn

Screen size

Shaft Diameter

Storage

Stroke length

Supply voltage DC

Supply voltage AC

Temperature range

Form Factor

Touch

Type of Switch

Voltage

dB(A)

Brands

Industrial box PCs – fanless embedded computers for cabinets, machines and vehicles

A box PC is a complete industrial computer in a closed, compact enclosure. It is mounted on a DIN rail, a wall or a rack and runs machine control, data collection, gateways, video analytics or AI close to the process – without a built-in screen. Most models are fanless with no moving parts, many are rated for operation down to −40 °C and accept wide-range DC power. SCN supplies box PCs from Axiomtek, IEI, Moxa, Aitech, Diamond Systems, AAEON and Winmate.

The range is grouped by use. Low performance, moderate performance and high performance are graded by processor. AI-at-the-edge computers with NVIDIA Jetson run AI models next to the cameras. There are also in-vehicle box PCs for trains, buses and work machines, marine box PCs, medical PCs and MIL and aircraft rugged systems. Need a built-in touch screen? Choose a panel PC.

How to choose: start with the processor performance and memory the application needs. Then list the interfaces: Ethernet ports (PoE for cameras), serial COM ports, USB, digital I/O, CAN and expansion slots for 4G/5G, Wi-Fi or fieldbus cards. Finally check mounting, operating temperature, power input and the certifications your environment requires. SCN's engineers help you configure the right system, including memory and storage.

Frequently asked questions

How does a fanless box PC stay cool?

The enclosure itself is the heatsink. Heat from the processor is led through heat pipes or thermal pads to the finned aluminium housing and released to the surrounding air. That is why fanless PCs use energy-efficient processors and need free air around the fins – and why they keep running in dust and dirt where a fan would clog.

Intel Atom, Intel Core or NVIDIA Jetson – which processor do I need?

Intel Atom and Celeron are enough for gateways, data logging, protocol conversion and simple HMIs. Intel Core and Xeon handle machine vision, SCADA servers, several screens and virtual machines. NVIDIA Jetson is the choice when AI models analyse camera streams – see AI-at-the-edge computing.

Which certifications are needed in trains, vehicles and ships?

Rail vehicles require EN 50155, which covers temperature and power supply, together with EN 61373 for shock and vibration. Road vehicles need E-mark (UN ECE R10) for electromagnetic compatibility. On ships, IEC 60945 and class approvals such as DNV apply. Each product's datasheet lists its certifications.

How long is an industrial box PC available?

Much longer than an office PC. Industrial box PCs are built on embedded processor platforms with long availability, manufacturers typically keep a model in production for five years or more and announce end-of-life in advance. That makes it possible to standardise on one model for a whole machine series.

Not sure which model you need?

Get help choosing
Read more in our guides

Facts and advice that make the choice easier.

IP ratings explained – IP65, IP67, IP68 and IP69KIndustrial PC – choosing a box PC, panel PC or rack PCEdge computing and AI – how to choose an industrial computerAll guides
