R81B High Voltage relays 7kV Normally closed (NC)
R81B High Voltage relays 7kV Normally closed (NC)
The Rincon Power R81B is a 7 kV normally closed (NC) high voltage relay for antenna tuning units and high voltage test equipment.
7 kV AC/DC, up to 10 A continuous carry
Tungsten contacts for make/break load switching
SPST-NC: conducts until the coil is energised
High dielectric encapsulant for strong external isolation
Hermetic, IP67 and IP69K rated, -50 to 85 °C
Panel or PCB mounting, 56 g
Coil 12 VDC or 26.5 VDC
Additional information
| Coil Voltage | 12 VDC, 26,5 VDC |
|---|---|
| Max system voltage | 7 kVAC, 7 kVDC |
| Mechanical cycles | 2.000.000 |
| Sector | Factory Automation |
| Contact config | Normally closed (NC), SPST |
| IP Classification | Hermetic, IP67, IP69K |
| Temperature range | -50°C ~ 85°C |
| Mounting | Panel, PCB |
| Shock | 30 G |
| Vibration | 10 G |
| Weight | 56 g |
| Response time | 10 ms |
