R20 High Voltage Relay 28kV SPST-NO
R20 High Voltage Relay 28kV SPST-NO
The Rincon Power R20 is a vacuum-sealed SPST-NO high voltage relay for 28 kV no-load switching in RF, medical, laser and test equipment.
28 kV peak, DC or 60 Hz
110 A continuous carry, 60 A at 2.5 MHz
Vacuum-sealed ceramic, molybdenum/copper contacts
M6 screw HV terminals, through-panel mount
Operate time 18 ms, 2 million cycles
12 or 26.5 VDC coil
-55 to +125 °C, 30 G shock, 345 g
Additional information
| Sector | Defence, Factory Automation |
|---|---|
| Coil Voltage | 12 VDC, 26,5 VDC |
| Max system voltage | 28 kVAC, 28 kVDC |
| Mechanical cycles | 2.000.000 |
| Contact config | Normally open (NO), SPST |
| Temperature range | -55°C ~ 125°C |
| Mounting | Panel |
| Continuous current | 110 A AC, 110 A DC |
| Shock | 30 G |
| Vibration | 10 G |
| Weight | 345 g |
| Response time | 18 ms |
