MRPF28 Non-Contact Magnetic Rotary Sensor
MRPF28 Non-Contact Magnetic Rotary Sensor
The Opkon MRPF28 rotary sensor is a non-contact magnetic angle sensor with absolute analogue output for 0 to 360° measurement in industrial machines.
12-bit single-turn resolution, ±0.5% accuracy
Up to 1000 rpm operating speed
Compact 28 mm case, 6 mm shaft
IP54 protection
0–5 V or 0–10 V output via cable
Flange mounting, 8–24 VDC supply range
Our guides help you choose the right product.
IP ratings explained – IP65, IP67, IP68 and IP69KAdditional information
| IP Classification | IP54 |
|---|---|
| Measuring technology | Potentiometer |
| Material | Plastic, Stainless steel |
| Communication Interface | Analog 0-10V, Analog 0-5V |
| Mounting | Flange, Rod |
| Electrical connection | cable |
| Supply voltage | 12 VDC, 15–24 VDC, 24 VDC, 8–24 VDC |
| Sector | Factory Automation |
| Temperature range | -20°C ~ 80°C |
| Measuring range | 0-360° |
| Accuracy | ±0,5% |
| Resolution Singleturn | 12bits |
| Max operating speed | 1000 rpm |
| Shaft diameter | 6mm |
| Measured variable | Position |
