G61LC High Voltage Relay Latching (CO) 35kV
G61LC High Voltage Relay Latching (CO) 35kV
G61LC is a compact latching change-over high-voltage relay that isolates up to 35 kVDC, suited to capacitive discharge and safety dump switching.
35 kVDC or 30 kVAC, 10 A continuous current
Effectively bounce-free operation
Operating temperature -55 °C to +85 °C
26.5 VDC latching coil, switched by a short pulse
Flying leads for versatile HV connections
1 million mechanical cycles, 336 g
Additional information
| Coil Voltage | 26,5 VDC |
|---|---|
| Max system voltage | 30 kVAC, 35 kVDC |
| Mechanical cycles | 1.000.000 |
| Sector | Factory Automation, Infrastructure & Energy |
| Continuous current | 10 A AC, 10 A DC |
| Contact config | Change over (CO), Latching |
| Temperature range | -55°C ~ 85°C |
| Weight | 336 g |
| Vibration | 10 G |
| Response time | 15 ms |
| Shock | 20 G |
