DRH-120 Power supply 120W Single Output High Input Voltage
DRH-120 Power supply 120W Single Output High Input Voltage
Mean Well DRH-120 is a 120 W single-output DIN rail power supply for high input voltages. It accepts 340–550 VAC or 480–780 VDC and is designed for industrial 400–500 VAC networks.
- 24 VDC / 5 A (DRH-120-24) or 48 VDC / 2.5 A (DRH-120-48)
- Efficiency up to 86 %, cooling by free air convection
- Protection against short circuit, overload, overvoltage and overtemperature
- Operating temperature -20 to +60 °C
- For TS-35/7.5 or 15 DIN rail, UL 60950-1
Our guides help you choose the right product.
Industrial power supplies – DIN rail, DC/DC and UPSAdditional information
| Output Voltage | 24 VDC, 48 VDC |
|---|---|
| Rated power | 120W |
| Sector | Factory Automation, Infrastructure & Energy, Medical & Life Science, Renewables |
| Phase | 3-phase |
| Supply voltage | 340–550 VAC, 480–780 VDC |
| Output current | 5 A DC |
| Efficiency | 86 % |
| Temperature range | -20°C ~ 60°C |
| Approvals | UL |
| Mounting | DIN rail |
| Dimensions | 65,5 x 125,2 x 100 mm |
| Weight | 0,75 kg |
| MTBF | 178.700 h |
| Vibration | 2 G |
| Cooling | Fanless |
