DMSS Profibus Magnetostrictive Position Linear Sensor
DMSS Profibus Magnetostrictive Position Linear Sensor
The Opkon DMSS Profibus magnetostrictive sensor is an aluminium profile sensor that delivers non-contact position values to PROFIBUS controllers in factory automation.
100 to 5000 mm measuring length
Aluminium profile housing rated IP65
Operating temperature from -10 to +70 °C
PROFIBUS interface on RS-485
M12 and M8 connector options
Runs on a 24 VDC supply
Our guides help you choose the right product.
IP ratings explained – IP65, IP67, IP68 and IP69KAdditional information
| IP Classification | IP65 |
|---|---|
| Stroke length | 100-5000mm |
| Measuring technology | Magnetostrictive |
| Material | Aluminium |
| Measuring range | 100-5000mm |
| Communication Interface | Profibus |
| Mounting | Profile |
| Electrical connection | M12 connector, M8 connector |
| Supply voltage | 24 VDC |
| Sector | Factory Automation |
| Temperature range | -10°C ~ 70°C |
| Fieldbus/Interface | Profibus, RS-485 |
| Serial standard | RS-422, RS-485 |
