Interface Programmable Incremental
Programming Functions PPR (1-16384), Output, Counting Direction Configuration Tool UBIFAST Configuration Tool (Version ≥ 1.6.3)

Outputs
Output Driver Push-Pull (HTL)
Output Voltage High Level Push-Pull (HTL) > 4 V @ 4.75-9 V Supply Voltage > V-3 V @ 9-30 V Supply Voltage
Output Voltage Low Level Push-Pull (HTL) < 0.5 V Output Voltage High Level RS422 (TTL) > 4 V
Output Voltage Low Level RS422 (TTL) < 0.5 V Maximum Frequency Response 1 MHz Maximum Switching Current 50 mA per Channel Electrical Data Supply Voltage 4.75 – 30 VDC Current Consumption ≤140mA @ 5V DC, ≤70mA @ 10V DC, ≤40mA @24V DC
