Aitech’s E152 6U VME Development Platform provides a versatile, easy to use, low cost
environment for development of 6U systems and application software.

The development platform includes a 4-slot VME64x backplane with rear I/O, an integral power supply, and a fan unit.
The E152 can be ordered without boards, or with one or more Aitech air-cooled 6U VME SBCs.

Functionality may be enhanced by adding Aitech or third party peripheral VME boards, additional
SBCs, and PMCs/XMCs to SBCs or PMC/XMC carriers.

SBC and PMC/XMC I/O can be easily accessed using transition modules with standard I/O connectors, assembled from the rear of the E152.

Refer to the datasheets for the various Aitech 6U VME SBCs, peripheral boards, PMCs, XMCs, PMC/XMC Carriers, and Transition Modules for more information regarding the potential capabilities of the E152 Development Platform.

The enclosure includes a modular 250 Watt power supply having the following characteristics.
• Input Power: 100 – 240 Vac @ 50 – 60Hz
• Output Power *
– +5Vdc @ 40A
– +3.3Vdc @ 40A
– +12Vdc @ 5.5A
– -12Vdc @ 2A
* Total power should not exceed 250W
• Output Protection
– Short circuit
– Overvoltage
– Overload
