EmCORE 3.5-inch Single Board Computers
EmCORE 3.5-inch Single Board Computers
3.5-inch single board computer for embedded industrial systems and machines, offering many serial ports and dual LVDS on a compact board.
AMD Ryzen Embedded R1102G with Vega graphics
Up to 16GB DDR4-2400 in one SO-DIMM
Operating range -20 to 70 °C
Six COM ports, 8 USB and dual GbE LAN
Two dual-channel LVDS plus DisplayPort, two active
Two Mini-Card sockets and micro SIM slot
8-bit digital I/O and two SATA ports
Additional information
| Processor | AMD Ryzen R1102G |
|---|---|
| Max memory | 16GB |
| Temperature range | -20°C ~ 70°C |
| Supply voltage | 8–13,2 VDC |
| Form factor | 3.5'' |
| LAN ports | 2 |
| USB ports | 8 |
| COM ports | 6 |
| Serial standard | RS-232, RS-422, RS-485 |
| Display outputs | 2 |
| Operating system | Linux, Windows |
| Dimensions | 146 x 102 mm |
| Sector | Factory Automation |
