SPECIFICATIONS

Contact Arrangement Form X, SPST NO
Max Switching Voltage 1000 VDC
Continuous Current (15mm2 conductor) 40A
Overload Current 30 seconds 80A
1 hour 30A
Max Break – 30A @ 450V 5 cycles
Max Short Circuit Current -0.5 second 200 A
Min Insulation Resistance 1,000 Mohm @ 500VDC
Contact Voltage Drop (Max) 50mV @ 10A
Operate Time (Max, incl bounce) 30ms
Release Time (Max) 10ms
Shock – Functional, 1/2 Sine, 11ms 20G
Shock – Destructive, 1/2 Sine, 11ms 50G
Operating Temperature -40˚C to 85˚C
Ingress Protection IP67
Mechanical life 200,000 cycles
Nominal Voltage 12 VDC or 24 VDC
Coil Power at Nominal Voltage 3W
