lr Cable Reel
lr Cable Reel
Demac LR is a cable reel series with built-in length and inclination sensors, for strokes up to 50 m on vehicles and mobile machines.
Two length sensors, optionally one angle sensor
Output in volt, mA or CANbus
Screened cable 3 to 12 poles, or steel wire rope
Max tension 50 V, max current 1A
Max cable speed 30 m/min, IP65
Temperature -20/+60°C, -40°C+80°C also available
Weight 14 to 29 kg
Additional information
| Function | Electrical |
|---|---|
| Modules | 1 |
| Sector | Vehicle Solutions |
| Temperature range | -40°C ~ 80°C |
| IP Classification | IP65 |
| Supply voltage | 10–30 VDC, 24 VDC |
| Fieldbus/Interface | CAN |
| Communication Interface | CANbus |
| Measuring range | 1 Axis 360° |
| Measured variable | Inclination, Length |
| Current per circuit | 1 A |
| Weight | 14 kg, 29 kg |
